Himac imaging, the HM0360 is an ultra-low power, back side Illuminated(BSI) cmos image sensor defigned for engergy efficient smart vision appications, such as object-specific classification, tracking anf identification.
The HM0360 VGA 0.3MP cmos sensor camera moduleThe advanced 3.6 unit low noise, deep diode and video capture in low lingt environments while miniziong the ues of external power consuming, LED illuminators.
HM0360 supports Quad and Channel sub-sampling and Quad binning readout for sub2 and sub4 for both Bayer RGB and Monochrome sensor CFA. The sub-sampling readout can be used tp reduce sensor resolution while preserving the field of view. The binning readout improves S/N ratio. The sub-sampling and binning moses can be configured in the main and context register banks.
Ultra low power, high sensitivity, low noise VGA sensor
Operates 8.6mA VGA 60FPS down to 256uA in monitor mode
Automatic wake and sleep operation with programmable even interrupt to wake host processor
On chip high precision oscillator, auto exposure/gain, amblent light sensor and zone detaction
Metered exposure provides well exposed first frame and after ecxtended dleep(blanking) period
key specifications (typical)
active array size: 656x 496/640 x 480
power supply:
analog: 2.8V
core: 1.2V
I/O: 1.8V/2.8V
Pixel size: 3.6umx3.6um/BSI
Image Diagonal: 2.88mm(1/6")
Shutter type: Eletronice Rolling shutter
Input reference clock: 6-24MHz
Internal Oscillator: 48MHz
Serial Interface: I2C(1MHz max, single/burst)
MIPI Date format: 8-bit
Parallel/serial data format: 8-bit, 4-bit+4-bit/4-bit/1-bit
